1100LPH Twin Screw Brushless In-Line Fuel Pump - 47415

1100 LPH @ 45PSI, 125PSI MAX -  13.5v - RATED UP TO 2800HP - Massive Power Support

Pump Features

• Compatible with gasoline, diesel, methanol, and ethanol
• Twin Screw Rotor Pumping Mechanism
• 125PSI Max Operating Pressure
• 2800HP power support at continuous speed
• Higher efficiency means less current draw and less noise
• Superior Priming Capabilities
• Greater resistance to cavitation (vapor lock)
• Backed by a limited lifetime warranty

Motor Features

• Lightweight super-efficient DC brushless motor to minimize current draw
• Powerful high flux density Neodymium rare earth magnets
• No motor brushes to wear out or corrode (low-Sulfur diesel, no problem)
• Wet motor design, no dynamic shaft seals that can wear out

Controller Features

• 12 to 16 volt vehicle electrical system compatibility
• Model 72006 Pump Controller included for Full Speed or PWM Input speed control
• Continuous duty motor speed

Construction Features

• Compact, lightweight design, less than 3lbs. Overall length 7.13”, diameter 2.0”
• Billet Aluminum Construction with anodize per MIL-A-8625, Type II
• Includes two billet aluminum mounting brackets
• Long Life, multi-fuel compatible Fluorosilicone static seals
• Accepts standard or port style -8AN fittings
