200GPH @ 20PSI Variable Speed Brushless Fuel Pump - 41404

41404
  • High Flow Carbureted In Line Fuel Pump, rated up to 2000HP, Street/Strip, Speed Adjustable DC Brushless fuel pump, External bypass
  • Limited Lifetime Warranty
Pricing: $740.00

Customize Your Item

- Select a Color -
 * required
Qty:

Description

200 GPH @ 20 PSI, 30 PSI MAX - RATED UP TO 2000HP - Developed from our successful 41403 model, we take all the benefits of a high flow in-line pump and integrate a bypass valve directly into the outlet assembly of the pump.

Pump Features

  • Compatible with gasoline, diesel, methanol, and ethanol
  • Externally bypassed at 30 PSI
  • High efficiency sling vane positive displacement pump
  • Special housing shape for extremely quiet operation and steady pressure
  • Carbon 9-vane construction with pressure balanced rotor for high reliability
  • Backed by a limited lifetime warranty

Motor Features

  • Lightweight super-efficient dc brushless motor reduces current draw
  • Low mass rotor for high speed reaction to changes in speed and flow
  • Powerful high flux density Neodymium rare earth magnets
  • No motor brushes to wear out or corrode (low-Sulfur diesel, no problem)
  • Wet motor design, no dynamic shaft seals that can wear out

Electronic Features

  • Internal speed controller for variable flow operation
  • 12 to 24 volt vehicle electrical system compatibility
  • Accepts PWM input for speed control
  • No expensive add-on voltage regulators or pump controllers required!
  • Continuous duty–motor speed can be adjusted to meet fuel demand

Construction Features

  • Compact, lightweight design, less than 3 lbs, overall length 6.9", diameter 2.63"
  • Billet Aluminum Construction with anodize per MIL-A-8625, Type II
  • High quality mounting brackets included
  • Long-life, multi-fuel compatible Fluorosilicone static seals!
  • Accepts standard or port style –10AN fittings

.

Technical Sheets

Shipping Information

  • Item Requires Shipping
  • 3.6 lbs.
  • W11.0000” x H4.0000” x L4.0000”
